Leviton SPLCS-2LL OPT-X SDX 12 Fiber Singlemode LC Splice Modules protect and organize heat-shrink fusion spliced fibers for installation in an SDX fiber enclosure orpanel. The modular design enables faster field splicing and simple management of pigtails within the housing. Splice modules eliminate the need for individual splice trays within a fiber enclosure and provide optimal organization and slack management of fibers. Typical applications include Wide Area Networks (WAN), campuses, high-count riser buildings, government installations, data centers, and central offices.

Construction features a 16-gauge metal adapter plate for robustness, chassis and cover polycarbonate for overall light weight.  Splice Modules are pre-loaded and routed with respective one-meter, color-coded individual 900 µm pigtail assembly. Individual pigtails have a maximum insertion loss of 0.25 dB for OS2 fiber types. Return Loss is greater than 55dB. LC adapters use use ceramic ferrules and provide IP5x-rated internal shutters compliant with IEC 60529. Module provides slack storage and bend radius protection for incoming backbone fibers, 900 µm tight-buffer fibers, and fusion-spliced fibers. Incoming 250 µm backbone fibers are protected by a braided mesh sleeve. Heat-shrink style splice sleeves, a braided mesh sleeve, and tie wraps are included with module.

• 12F - Singlemode - LC/UPC
• Modules integrate fiber adapter bulkhead and splice holders, eliminating need of splice trays
• Integrated latching tabs allow for one-handed insertion andremoval from SDX enclosures and panels
• 12-fiber color-coded 900 µm pigtail assembly allows for easy identification when fusion splicing
•  Patented internal shutters on LC adapters eliminate the need for dust plugs to reduce waste, speed up deployment,and ensure safer installations
•  Modular design allows for easy maintenance of individual spliced fiber and scaling up without impacting adjacent fibers
•  Accessory kit includes heat-shrink splice sleeves, braided mesh sleeve, build-up tape and tie wraps
